TDA7491MV

Features
■ 20 W continuous output power:
RL = 8 Ω, THD = 10% at VCC = 18 V
■ 25 W continuous output power:
RL = 6 Ω, THD = 10% at VCC = 16 V
■ Wide range single supply operation (5 V - 18 V)
■ High efficiency (η = 90%)
■ Four selectable, fixed gain settings of 20 dB,
26 dB, 30 dB and 32 dB
■ Differential inputs minimize common-mode
noise
■ Filterless operation
■ No ‘pop’ at turn-on/off
■ Standby and mute features
■ Short circuit protection
■ Thermal overload protection
■ Externally synchronizable

PowerSSO-36
